SMART IOT CONTROLLER
NUVEQ Smart IoT Controller is an advanced access control system that combines the power of the Internet of Things (IoT) with modern security technology. This device provides an intelligent and automated solution for managing access to facilities, enhancing security and convenience. NUVEQ Smart ioT Controller combines robust access control technology with a user-friendly cloud-based management platform that offers a simple, secure, and scalable way to manage access to facilities and doors across your organization.
Plug & Play
-
No servers, workstations required
-
Doors come online and configured in minutes
-
No added software or complexities like port forwarding
-
Centralized management for seamless access anywhere
READY FOR SCALE
-
Cloud-based platform has no door/user limits
-
Scale to thousands of doors across all locations
-
No need to create virtual networks to sync access across sites
CLOUD-MANAGED SOLUTION
-
Secure remote access on any device anywhere
-
Continuous updates with new features
-
Automatic firmware updates keep systems secure
-
New features and enhancements are added at no additional costs
Integrates with onsite Fire alarm systems to unlock doors automatically in the event of emergency.
Allows only one door to remain open at a time. An Effective Security Measure for Restricted Areas
Prevent unauthorized access and discourage tailgating
Allows only one door to remain open at a
time. An Effective Security Measure for
restricted areas
Future proof your investment, by getting the latest features and updates.
-
Automatically receive the latest feature updates
-
remotely update the code on the devices
-
seamless updates across all devices in an IoT system
-
Avoid long downtimes related to on-premise access control servers
Over the Air(OTA)
Firmware Updates
System Architecture
technical
specification
Operation modes:
-
Single door mode
-
Two door mode
-
Elevator mode
-
Barrier mode
-
Alarm Monitoring Mode
Power Fail Monitor:
Yes
Global Anti-Passback:
Yes - No additional hardware necessary
WAN Support:
Google Cloud connected
Firmware Upgrade: Over the air (OTA) update
Power:
12VDC, 8W
Casing Dimension:
290mm (H) x 320mm (W) x 78mm (D)
Enclosure Type:
Metal Enclosure with mechanical key
Certificate:
CE, RoSH, UKCA
Compliance:
EN55032, EN55035, IEC61000
Processor:
STM32 ARM Cortex M4 (32bit) @ 150MHz
No of Doors:
2 Doors
Reader Input:
-
Max of 4
-
Supporting Wiegand 26/34/44 bit card readers
-
Mifare, HID, Desfire, QR Code
-
Bluetooth/NFC reader(RS-485 AES256 Encrypted)
Card Holder/transactions:
-
130,000 card users
-
130,000 transaction buffer
Inputs:
-
2 x door sensor inputs
-
2 x REX pushbutton inputs
-
4 x general purpose inputs
-
1 fire alarm input
-
3 configurable as Tamper, Power Failure, Battery Low
-
256 Alarm Inputs (EP-16IO x 16)
Outputs:
-
4 x Relay outputs, switchable to NO or NC operation
-
2 x card reader LED outputs
-
2 x card reader Buzzer outputs
-
256 Alarm Outputs (EP-16IO x 16)
Serial ports:
-
3 x RS485 serial ports
-
Protected against surges, overvoltage and ground faults
Take the first step towards a more secure and efficient access control system.
Contact us today to learn more about NUVEQ's cloud-based access control system and request a demo. Secure your building and streamline your operations with NUVEQ.
Learn more about our products
EP-30NB
BLE/NFC Reader
EP-FR701
Outdoor Face Recognition Terminal
EP-TP303N
Tripod Turnstile
Auxiliary Inputs
Fire Alarm
Integrates with onsite Fire alarm systems to unlock doors automatically in the event of emergency.
Tamper Alarm
To detect and alert when an attempt is made to interfere with, disable, or tamper with a security device or system
AC Power Failure Detection
Ensuring that essential systems remain operational or appropriate measures are taken in the event of a power outage
Low Battery Detection
Alerts users or system administrators when the battery charge is running low, allowing for timely replacement or recharging.
Secure Bluetooth, NFC, QR code credentials (AES 256 Encrypted)
-
2 Door
-
Up to 4 readers
-
Wiegand 26/34/44 bit
Google Cloud
Emergency Door Release
Emergency Lockdown
CE, RoSH, UKCA
EN55032, EN55035, IEC61000
Over the air update(OTA)
ARM Cortex M4 (32bit) @ 150MHz
130,000 card users
130,000 transactions
Auxiliary Inputs: 256
Relay Ouputs: 256
-
Uniquely Identified ByMAC address.
-
Ethernet connection Dynamic IP (No on-site configuration).
-
Remote access control.
-
Users can manage door access from anywhere using smartphones or computers, making it convenient to allow entry without being physically present.
-
Easily Expandable.
-
IoT controller can be easily expanded to include additional doors or entry points without significant changes to the existing infrastructure.
-
Over the Air(OTA)
-
Firmware Update.Automatically receive the latest feature updates.
Smart loT Controller
Next-generation loT controller offers unparalleled connectivity for your devices, ensuring that your operations run seamlessly.
